The SIM7670/SIM7672 series is the LTE Cat 1bis module based on the latest QCX216 chipset that supports wireless communication modes of LTE-FDD/LTE-TDD. It supports maximum 10Mbps downlink rate and 5Mbps uplink rate.
| Part Number | SIM7670NA | |
| Manufacturer | SIMCom | |
| Description | The SIM7670/SIM7672 series is the LTE Cat 1bis module based on the latest QCX216 chipset that supports wireless communication modes of LTE-FDD/LTE-TDD. It supports maximum 10Mbps downlink rate and 5Mbps uplink rate. |
|
| Category | IoT Modules | |
| Lead Time | 8 weeks | |
| Country of Origin | ||
| Datasheet | Datasheet | |
Product Attributes
| TYPE | DESCRIPTION |
|---|---|
| Ambient Temperature Range High | 85° C |
| Ambient Temperature Range Low | -40° C |
| Length | 24 mm |
| Weight | 2.83g |
| Width | 24 mm |
| Thickness | 2.4 mm |
| Number of Bands | 8 |
| USB Standard | 2.0 |
| Nominal Input Voltage | 3.8 |
| Approvals - Carrier | AT&T, Verizon, T-mobile |
| Approvals – Regulatory | FCC, IC, GCF, PTCRB, RoHS, REACH |
| Connector Type | LCC+LGA |
| Country of Origin | China |
| Max Input Voltage | 4.2 |
| Min Input Voltage | 3.4 |
| Number of A/D Converters | 2.0 |
| Number of Analog Inputs | 2.0 |
| Number of I2C Channels | 1 |
| Number of UART Channels | 3 |
| Number of USB Channels | 1 |
| Mount | SMD |
| Data Rate | LTE: 10(DL)/5(UL) Mbps |
| Number of ADC Channels | 2.0 |
| Number of GPIO | 11.0 |
