The SIM7000 series is the LPWA module which supports wireless communication modes of Cat- M/Cat-NB/GPRS/EDGE.
Product Attributes
| TYPE | DESCRIPTION |
|---|---|
| Ambient Temperature Range High | 85° C |
| Ambient Temperature Range Low | -40° C |
| Length | 24 mm |
| Weight | 3 g |
| Width | 24 mm |
| Thickness | 2.6 mm |
| Number of Bands | 4 |
| USB Standard | 2.0 |
| Current | PSM: 9 µA Sleep 1 mA Idle 11 mA |
| Nominal Input Voltage | 3.8 |
| Approvals - Carrier | AT&T, VERIZON, ROGERS |
| Approvals – Regulatory | FCC, ICC, PTCRB, GCF, RoHS, REACH |
| Connector Type | LCC |
| Country of Origin | China |
| Max Input Voltage | 4.3 |
| Min Input Voltage | 3.0 |
| Number of A/D Converters | 1.0 |
| Number of Analog Inputs | 1.0 |
| Number of I2C Channels | 1 |
| Number of UART Channels | 1 |
| Number of USB Channels | 1 |
| Mount | SMD |
| Data Rate | Cat-M 300(DL)/375(UL) kbps Cat-NB 34(DL)/66(UL) kbps |
| Number of ADC Channels | 1.0 |
| Number of GPIO | 4.0 |
