Aluminum Electrolytic Capacitors - SMD Aluminum Electrolytic Capacitors - SMD 330uF 50volts 10x10.2mm SMD
Product Attributes
| TYPE | DESCRIPTION |
|---|---|
| ESR | 120 mΩ |
| Diameter | 10 mm |
| Length | 10.5 mm |
| Lifecycle Status | Production |
| Height | 10.5 mm |
| Leakage Current | 165 µA |
| Country of Origin | China |
| Lifetime @ Temperature | 2000Hour |
| Minimum Operating Temperature | -55 °C |
| Maximum Operating Temperature | 105 °C |
| Ripple Current @ Low Frequency | 585 mA @ 120 Hz |
| Ripple Current @ High Frequency | 900 mA @ 100 kHz |
| Minimum Order Qty | 20000 |
| SPQ | 500 |
| Type of Packaging | REEL |
| Manufacturing Lead Time | 20 |
| Product Status | Active |
| Voltage Rating | 50V |
| Capacitance | 330uF |
| Tolerance | 0.2 |
| Impedance | 120 mΩ |
ADD TO CART
2000
On Stock
